DIN EN 10130 DC 01 cold rolled panel sheet.
33.3 mm pitch water channels with aesthetic design.
Compact or Ventil Compact production option.
Vertical Monoblock striped or unlined plane surface options.,
Each panel is subjected to a radiator leak test.
Test pressure: 13 bar
Maximum working pressure: 10 bar
Maximum operating temperature: 110 sıcakC
Production according to TS EN 442 standards.
Nano-technological surface treatment with high corrosion resistance.
Environmentally friendly water based primer paint and RAL 9016 epoxy polyester electrostatic powder coating.
Panel radiators, whose painting operation is completed, are prepared in accordance with the transportation and storage conditions in the automatic packaging line. Styrofoam foam prevents damage to the surface.
Mounting accessories consisting of blind plugs, plugs, plugs, clips, triplex screws are included in the package as standard.
FC Console is supplied as standard.
The thermostatic valve and thermostat core are available on request.
4 x G ½ G connection - 6 x G ½ G connection
