DIN EN 10130 DC 01 cold rolled panel and convector sheet.
33.3 mm pitch water channels with aesthetic design.
Maximum convection surface area with maximum thermal power.
Each panel is subjected to a radiator leak test.
Test pressure: 13 bar
Maximum working pressure: 10 bar
Maximum operating temperature: 110 sıcakC
Production according to TS EN 442 standards.
Nano-technological surface treatment with high corrosion resistance.
Environmentally friendly water based primer paint and RAL 9016 epoxy polyester electrostatic powder coating.
Panel radiators, whose painting operation is completed, are prepared in accordance with the transportation and storage conditions in the automatic packaging line. Plastic mensol protector prevents damage to the hanger connection and the radiator side covers are covered with cardboard lids.
Mounting accessories consisting of L-Cantilever, blind plug, solenoid plug, plug, clip, triple screw are included in the package as standard.
4 x G ½ connection.
